01BAG IN DRUM
Aseptic Bag-in-Drum Filling Machines
For bulk food ingredients, the filling head, aseptic liner and drum handling must work as one cell. Start with the actual drum and bag, then choose the head arrangement.
FOOD & INGREDIENT ASEPTIC FILLING
Aseptic bag filling.
Choose your filling cell.
Aseptic bag filling machines for 1–25 L bag-in-box, 200 L bag-in-drum and 1000–1500 L bulk liners. Compare the AF models by package, head count and metering — then define the product and acceptance basis.
- 01Package first: BIB, BID or BIC
- 02AF1 / AF2 model comparison
- 03Product and fitment confirmed in the trial
STEAM-STERILISED FILLING INTERFACE
REFERENCE MODELAF1D
PACKAGE200–220 L
PUBLISHED MAX.12 t/h
Twin-head installation photograph: EasyReal AF-series, source easireal.com. Catalogue maximum, not a line guarantee.
CHOOSE THE MACHINE
Four AF models, compared in one place.
Choose the package independently, then compare heads, metering and the complete filling cycle.
| Model | Package | Heads | Metering | Reference maximum | Product review | Confirm before order |
|---|---|---|---|---|---|---|
| AF1S | Bag-in-drum 200 / 220 L | Single | Weighing or flow | up to 6 t/h | Juice, purée or concentrate at the agreed filling condition | Product trial, bag/cap drawing, complete cycle and agreed net-fill criteria |
| AF1D | Bag-in-drum 200 / 220 L | Twin | Weighing or flow | up to 12 t/h | Juice, purée or concentrate at the agreed filling condition | Product trial, bag/cap drawing, complete cycle and agreed net-fill criteria |
| AF2S | Bag-in-box 1–25 L | Single | Flow meter | up to 3 t/h | Small-pack liquid foods; check viscous or particulate duty | Product trial, bag/cap drawing, complete cycle and agreed net-fill criteria |
| AF2D | Bag-in-box 1–25 L | Twin | Flow meter | up to 5 t/h | Small-pack liquid foods; check viscous or particulate duty | Product trial, bag/cap drawing, complete cycle and agreed net-fill criteria |
START WITH THE PACKAGE
Three package families. Three different cells.
The bag size is only the beginning. Fitment, support, weighing and container movement change the machine.
01
02BAG IN BOX
Aseptic Bag-in-Box Filling Machines
Smaller packages change the work cycle. Match the aseptic bag interface to bag support, box insertion and downstream packing before selecting the filling configuration.
03BAG IN BIN
Aseptic Bag-in-Bin & Tote Filling
Bulk bins and totes put container access and load movement at the centre of selection. Define the liner, filled mass and handling route before fixing the filling-cell layout.
FIND THE STARTING MODEL
Three answers. A sensible starting point.
This selector uses the published AF model matrix. It narrows the conversation; it does not replace a product and package trial.
01 / PACKAGE
02 / OUTPUT
03 / PRIORITY
PRODUCT APPLICATIONS
The product decides the filling duty.
01
Juice & Liquid Ingredients
Inlet conditions, foam, pulp and final fill control for clear and pulpy juices.
Review the product duty ↗02Fruit Purée & Concentrate
Viscosity, fibre, transfer and residue removal for purée and concentrate.
Review the product duty ↗03Products with Particles
Particle passage, product protection and representative trials.
Review the product duty ↗THE STERILE SEQUENCE
The filler protects the product. It does not sterilise it.
Product sterilisation happens upstream. The filling cell receives treated product, protects the bag interface, fills and closes the package. The boundary between upstream, filler and package must be defined and tested.
Understand the sterile boundary- 01Upstream product treatmentUHT or other validated process
- 02Sterile transferDefined temperature, pressure and flow
- 03Fitment treatmentProtected interface before filling
- 04Fill and closeMetered fill, cap and inspection
- 05CIP / SIPCleaning and pre-sterilisation, separately verified
LOOK AT THE INTERFACE
The machine is the head, the handling and the records.
A filling head is a mechanical, thermal and control interface. It engages the fitment, treats the connection, controls the fill and closes the package. Around it, the drum or box support, weighing, conveyor and cleaning circuit determine whether the cell works.
- Filling headSteam treatment, product valve, cap handling and protected zone.
- Package supportDrum, box or IBC liner carried by the container, not the fitment.
- MeteringFlow meter or weighing, with an acceptance method for the actual product.
- RecordsRecipes, alarms, cleaning and sterilisation sequence evidence.
BUYER GUIDES
Read before you compare quotations.
GUIDE
Single-Head vs Twin-Head Aseptic Fillers
Which tasks can overlap, and when a second head does not double output.
Read the guide ↗GUIDEFlow Meter vs Weighing for Aseptic Filling
Choose the metering method by product, package and acceptance.
Read the guide ↗GUIDEAseptic Bag Fitment Compatibility Guide
Check the bag neck, cap and head as one interface.
Read the guide ↗NEWS & TECHNICAL NOTES
The questions behind the equipment choice.
TECHNICAL APPLICATION · 28 October 2026
Aseptic Bag Fitments Are Part of the Product-Process Brief
A bag fitment is a sterile-interface component, not a late procurement detail. Build the product, package, connection and evidence questions into one reviewable brief.
Read the analysis ↗TECHNICAL SELECTION · 28 October 2026Product Sterilisation and Aseptic Filling Need One Reviewed Boundary
The filler protects a sterile product; it does not create one. Define the hold tube, transfer, filling head, package and restart authority as one reviewed boundary.
Read the analysis ↗MANUFACTURER & SUPPLY SCOPE
Real equipment. A clear boundary.
The AF-series aseptic bag filling equipment is manufactured by Shanghai EasyReal Machinery Co., Ltd. This site is the dedicated aseptic bag filling resource for asepticbagfillingmachine.com. Model availability, scope, documentation and quotation are confirmed in writing.
We do not display certificates, customer projects, factory claims or prices that have not been verified for this site. Where the catalogue does not publish a value, the page says so.
Review the technical references →2011EasyReal established, Shanghai
AF1–AF4Published aseptic bag filling families
1–1500 LBIB, BID and BIC package range
FAT / SATAcceptance scope defined per project
BEFORE YOU ASK
The questions that make the enquiry useful.
What is the difference between AF1 and AF2?
AF1 is the bag-in-drum platform for 200/220 L bags. AF2 is the bag-in-box platform for 1–25 L bags. The package handling, support and metering differ, so the model choice starts with the package.
Does the machine sterilise the product?
No. Product sterilisation is an upstream process such as UHT. The filler protects the treated product at the bag interface, fills and closes the package.
Can I get a price from the catalogue?
No honest catalogue price covers the scope. The cost depends on the model, heads, package, metering, automation, conveyors, utilities, documentation and validation. Send the product and package for a project-specific quotation.
Can you confirm a model for my product?
We can narrow the model from the package, output and product data. A representative trial is still needed for viscous, fibrous or particulate products. The page will state what remains unverified.
YOUR PRODUCT. YOUR PACKAGE. YOUR PROJECT.
Start with the bag and the product.
Send the package, target net mass, output and product condition. Add the fitment drawing and site utilities when available.
